Turbosound iX12 User Manual

14 iX Series Quick Start Guide 15
iX Series Bluetooth Instructions
Bluetooth Connection
To play audio from a Bluetooth-enabled device, you will need at least one iX speaker and an iPad*/iPhone*/Android*/Windows* device with basic Bluetooth
connectivity. With a basic Bluetooth connection, allrelated iX DSP functions must still be controlled directly from the iX rear panel via the rotary encoder.
For Apple iOS devices, you can also download a dedicated Turbosound iX Bluetooth app from the AppleApp Store. This iX Bluetooth app allows you to control a single
or stereo pair of iX speakers, including all DSP functions, remotely from your iOS device (see “Bluetooth Control” below for moreinformation).
Bluetooth Streaming
To Stream Bluetooth Audio with Any Bluetooth Device (iPad/iPhone/Android/Windows, etc.)
Mono operation
1. Enable Bluetooth on your remote device.
2. Switch on your iX speaker and minimize the volume.
3. Select “Pair device” from the SLAVE speaker’s Bluetooth menu.
1. Check that your remote device is searching for a connection.
2. Once your device detects the iX speaker, select the iX speaker from your remote device’s menu (e.g.,“Turbosound iX12”).
3. Wait until the remote device shows an active connection, and then check the speaker’s Bluetooth menu, which should display the name of the
remote device (e.g., “Coolpad8150”).
1. Bluetooth music can now be streamed to your iX speaker. The stereo signal will automatically mix down tomono.
2. The iX speaker will display the Bluetooth indicator on the main, top-level DSP screen.
Stereo operation
1. Complete the steps above to connect the rst speaker to Bluetooth audio.
2. The rst connected speaker automatically becomes the MASTER speaker.
3. Switch on the second speaker, which becomes the SLAVE speaker.
4. Select “Link speaker” from the SLAVE speaker’s Bluetooth menu.
5. The SLAVE speaker will display “Slave linking...”
6. Select “Link speaker” from the MASTER speaker’s Bluetooth menu.
7. The MASTER speaker will display “Master Linking…”
8. WAIT for the speakers to link.
9. Once the linking process is complete, Bluetooth audio will stream to the two speakers. The MASTER speaker will receive the left channel,
and the SLAVE speaker will receive the right channel.
10. MASTER and SLAVE connection will be indicated on the main, top-level DSP screens.
NOTE: These Bluetooth speakers can only link with another speaker of the same model (e.g.,aniX12speaker can only be paired with another iX 12 speaker).
Bluetooth Control
A dedicated iOS control app for iX speakers can be downloaded from the Apple Store.
• In both mono and stereo mode, rst pair the MASTER speaker, and then launch the iOS control app.
• The iOS control app will automatically detect and adapt for mono or stereo mode.
• To alter the speaker settings, swipe the screen or press the settings icon. All iX speaker settings can be accessed from the iOS control app.
Main Page (1 speaker) Main Page (2 speakers linked) Settings/EQ Page
IMPORTANT NOTE: The mounting of a permanently installed sound system may be dangerous unless undertaken by qualied personnel with the required experience and
certication to perform the necessary tasks. Walls, oors or ceilings must be capable of safely and securely supporting the actual load. Themounting accessory used must be
safely and securely xed both to the loudspeaker and to the wall, oor or ceiling.
When mounting rigging components on walls, oors or ceilings, ensure that all xings and fasteners used are of an appropriate size and load rating. Wall and ceiling
claddings, and the construction and composition of walls and ceilings, all need to be taken into account when determining whether a particular xing arrangement can be
safely employed for a particular load. Cavity plugs or other specialist xings, if required, must be of an appropriate type, and must be tted and used in accordance with the
maker’sinstructions.
The operation of your speaker cabinet as part of a own system, if installed incorrectly and improperly, canpotentially expose persons to serious health risks and
even death. In addition, please ensure that electrical, mechanical and acoustic considerations are discussed with qualied and certied (by local state or national
authorities) personnel prior to any installation or ying.
Make sure that speaker cabinets are set up and own by qualied and certied personnel only, using dedicated equipment and original parts and components
delivered with the unit. If any parts or components are missing please contact your Dealer before attempting to set up the system.
Be sure to observe the local, state and other safety regulations applicable in your country. Music Tribe, including the Music Tribe companies listed on the enclosed
“Service Information Sheet”, assumes no liability for any damage or personal injury resulting from improper use, installation or operation of the product. Regular
checks must be conducted by qualied personnel to ensure that the system remains in a secure and stable condition. Make sure that, where the speaker is own, the
area underneath the speaker is free of human trac. Do not y the speaker in areas that can be entered or used by members of the public.
Speakers create a magnetic eld, even if not in operation. Therefore, please keep all materials that can be aected by such elds (discs, computers, monitors, etc)
at a safe distance. A safe distance is usually between 1 and 2 metres.

Turbosound iX12 Specifications

General

Brand	Turbosound
Model	iX12
Category	Speaker System
Language	English
