LMS-D4 user manual
Page 14
Set the signal delay on the specified output channel. The delays can be adjusted in 20.83 uS
increments, with a maximum value of 20.7 ms (≡ 7.1 metres) in stereo two way configurations, and
42 ms (≡ 14.4 metres) in mono three way configurations. These delays are provided (their range is
large enough) to align the driver components in the time domain – including separate sub-bass
cabinets – but will not replace a dedicated delay line unit in applications such as distributed
systems.
Please also note that, as with other similar digital processing units, the values displayed are
relative
and do not take into account the basic processing delay of the unit which is approximately
0.4ms.
When adjusting the delay on bi-amped loudspeakers it is important to ensure the difference
between channels remains fixed so that the HF and LF drivers stay aligned.
8) Store Setup
The settings of this particular setup can be saved so that when it is next recalled, the user edited
value will return to their preferred settings.
Store Setup
