Turbosound TFM122M User Manual

12 TFM Series Quick Start Guide 13
Technical Speci cations
TFM122M TFM152M
System
Frequency response
70 Hz – 18 kHz ±3 dB
63 Hz – 20 kHz -10 dB
65 Hz – 18 kHz ±3 dB
50 Hz – 20 kHz -10 dB
Nominal dispersion 60° H x 40° V @ -6 dB points, rotatable 60° H x 40° V @ -6 dB points, rotatable
Directivity factor (Q) 18.3 18.3
Directivity index (DI) 12.6 12.6
Power handling (IEC)
Passive 350 W continuous, 1,400 W peak 350 W continuous, 1,400 W peak
Bi-amp
LF: 310 W continuous, 1,240 W peak
HF: 40 W Continuous, 160 W peak
LF: 310 W continuous, 1,240 W peak
HF: 40 W Continuous, 160 W peak
Sensitivity 96 dB (1 W @ 1 m) 98 dB (1 W @ 1 m)
Maximum SPL
Passive 122 dB continuous, 128 dB peak 124 dB continuous, 130 dB peak
Bi-amp
LF: 121 dB continuous, 127 dB peak
HF: 123 dB continuous, 129 dB peak
LF: 123 dB continuous, 129 dB peak
HF: 123 dB continuous, 129 dB peak
Impedance
Passive 8 Ω 8 Ω
Bi-amp
LF: 8 
HF: 8 
LF: 8 
HF: 8 
Crossover type Passive / bi-amp switchable Passive / bi-amp switchable
Components
1 x 12" (315 mm) LF driver
1 x 1.4" (33 mm) HF compression driver
1 x 15" (393.5 mm) LF driver
1 x 1.4" (33 mm) HF compression driver
Enclosure
Connectors 2 x Neutrik speakON NL4 2 x Neutrik speakON NL4
Wiring
Passive Pins 1+ / 1- input, pins 2+ / 2- link Pins 1+ / 1- input, pins 2+ / 2- link
Bi-amp Pins 1+ / 1- LF, pins 2+ / 2- HF Pins 1+ / 1- LF, pins 2+ / 2- HF
Dimensions (H x W x D) 302 x 452 x 504 mm (11.9 x 17.8 x 19.9") 351 x 530 x 565 mm (13.8 x 20.9 x 22.3")
Net weight 15.5 kg (34.1 lbs) 19.4 kg (42.7 lbs)
Construction 15 mm (⁄") birch plywood+Polypropylene plastic 15 mm (⁄") birch plywood+Polypropylene plastic
Finish Semi-matt black paint Semi-matt black paint
Grille Powder-coated perforated steel Powder-coated perforated steel
Flying hardware N/A N/A
Other important information
1. Register online. Please register your new
MUSIC Group equipment right after you purchase it by visiting
turbosound. com. Registering your purchase using our simple
online form helps us to process your repair claims more
quickly and e ciently. Also, read the terms and conditions of
our warranty, ifapplicable.
2. Malfunction. Should your MUSICGroup Authorized
Reseller not be located in your vicinity, youmay contact
the MUSICGroup Authorized Ful ller for your country listed
under “Support” at turbosound. com. Shouldyour country
not be listed, please check if your problem can be dealt with
by our “OnlineSupport” which may also be found under
“Support” at turbosound. com. Alternatively, please submit an
online warranty claim at turbosound. com BEFORE returning
theproduct.
3. Power Connections. Beforeplugging the unit
into a power socket, pleasemake sure you are using the
correct mains voltage for your particular model. Faultyfuses
must be replaced with fuses of the same typeand rating
withoutexception.
Important information

Turbosound TFM122M Specifications

General

Brand	Turbosound
Model	TFM122M
Category	Monitor
Language	English
