EDGE-R-RITE MODEL N2
17
85303
1 499074 Washer, Flat,
49/64” ID x 1-5/16” OD x 3/64” Thick ................. AR
2 655431 Wheel/Tire Assembly .............................................. 3
3 458013 Ring, Retaining, 3/4” ............................................... 2
4 655369 Bumper .................................................................... 1
5 443112 Nut, Hex, 3/8”-24 ..................................................... 4
6 446142 Washer, Lock, 3/8” ................................................ 10
7 655387 Plate, Catch ............................................................. 1
8 400298 Screw, Hex, 3/8”-24 x 1” .......................................... 4
9 461359 Pin, Spring, 1/8” x 3/4” ............................................ 1
10 443104 Nut, Hex, 1/4”-28 ..................................................... 4
11 446128 Washer, Lock, 1/4” .................................................. 4
12 452002 Washer, Flat,
1/4” ID x 9/16” OD x 3/64” Thick ........................... 4
13 655394 Trigger ..................................................................... 1
14 655393 Guide, Trigger ......................................................... 2
15 400152 Screw, Hex, 1/4”-28 x 1-1/4” ................................... 4
16 499035 Nut, 1/2”-20 Thin Flexloc ......................................... 1
17 655388 Handle, Control, Includes Item 22 ........................... 1
18 400458 Screw, Hex, 1/2”-20 x 4-1/2” ................................... 1
19 661472 Nozzle, Grease ....................................................... 1
20 458021 Ring, Retaining, 1” .................................................. 1
21 499128 Washer, Flat,
1-1/64” ID x 1-3/4” OD x 3/64” Thick .................. AR
22 654996 Bearing, Oilite, AA-1325-10 ..................................... 2
23 651381 Spring, Trigger ......................................................... 1
24 452010 Washer, Flat,
1/2” ID x 1-1/4” OD x 5/64” Thick .......................... 2
25 650572 Bearing, Oilite, AA-1043-9 ....................................... 2
26 471214 Fitting, Grease, 1/4”-28 Straight .............................. 1
27 654429 Arm Assembly,
Includes Items 25, 26, 32 and 33 .......................... 1
28 650859 Bushing, Cutting Arm .............................................. 1
29 443110 Nut, Hex, 3/8”-16 ..................................................... 8
30 655404 Guide, Cutting Arm .................................................. 1
Edge-R-Rite Model N2
31 499357 Nut, Hex, 3/8-16 Thin Flexloc .................................. 2
32 444812 Nut, Hex, 3/8”-24 Flexloc ........................................ 5
33 499167 Washer, Flat,
25/64” ID x 3/4” OD x 9/64” Thick ......................... 2
34 499059 Washer, Flat,
25/64” ID x 1-1/4” OD x 3/32” Thick ...................... 3
35 655427 Spindle, Wheel ........................................................ 1
36 655567 Bearing, Oilite, AA-1704-4 ....................................... 1
37 655663 Bracket, Support,
Includes Items 36 and 38 ...................................... 1
38 655662 Cover, Oil Hole ........................................................ 1
39 452006 Washer, Flat,
3/8” ID x 7/8” OD x 5/64” Thick ............................. 6
40 400312 Screw, Hex, 3/8”-24 x 3” .......................................... 1
41 440118 Bolt, Carriage, 3/8”-16 x 1” ...................................... 6
42 655677 Frame ...................................................................... 1
43 400194 Screw, Hex, 5/16”-18 x 1-3/4” ................................. 2
44 400306 Screw, Hex, 3/8”-24 x 2” .......................................... 2
45 650574 Bushing, Eccentric .................................................. 1
46 415509 Screw, Set, 1/4”-20 x 1/4” ........................................ 1
47 656889 Eccentric ................................................................. 1
48 499496 Key, 3/16” Square x 3/4” ......................................... 1
49 444808 Nut, Hex, 5/16”-18 Flexloc ...................................... 5
50 655671 Bracket, Upper Engine Mount ................................. 1
51 659991 Engine, Briggs and Stratton IC, 3.5 HP ................... 1
52 655418 Handlebar ................................................................ 1
53 659274 Grip, Handlebar ....................................................... 2
54 499492 Washer, Curved Spring,
3/4” ID x 1-1/8” OD x 1/32” Thick .......................... 1
55 452008 Washer, Flat,
7/16” ID x 1” OD x 5/64” Thick .............................. 4
56 655679 Manual, Operator and Parts List ............................. 1
57 655684 Decal Set, Green, Domestic .................................... 1
AR - As Required
Item Part Description Qty.
No. No.
Item Part Description Qty.
No. No.
PARTS LISTS
