EDGE-R-RITE MODEL N2
19
85303
Traction Kit
1 656771 Handle, Control, Includes Item 7 ............................. 1
2 499021 Washer, Flat,
25/64” ID x 5/8” OD x 1/16” Thick ......................... 3
3 460014 Pin, Cotter, 3/32” x 3/4” ........................................... 1
4 400310 Screw, Hex, 3/8”-24 x 2-1/2” ................................... 1
5 452006 Washer, Flat,
3/8” ID x 7/8” OD x 5/64” Thick ............................. 2
6 657208 Grip, Handle, Rectangular ....................................... 1
7 650700 Bearing, Oilite, AA-744-10 ....................................... 1
8 651065 Bushing ................................................................... 1
9 444760 Nut, Hex, 3/8”-24, Thin Flexloc ............................... 2
10 400440 Screw, Hex, 1/2”-20 x 1-1/4” ................................... 1
11 650467 Bushing, Eccentric .................................................. 1
12 444830 Nut, Hex, 1/4”-20 Flexloc ........................................ 3
13 452010 Washer, Flat,
1/2” ID x 1-1/4” OD x 5/64” Thick .......................... 2
14 655676 Bushing, Clutch Pivot .............................................. 1
15 650790 Spacer, Bushing, Pivot Fitting ................................. 1
16 650783 Fitting, Pivot, Rod End ............................................ 1
17 443112 Nut, Hex, 3/8”-24 ..................................................... 2
18 650635 Spring ...................................................................... 1
19 499035 Nut, Hex, 1/2”-20 Thin Flexloc ................................ 1
20 443812 Nut, Hex, 3/8”-24 Thin ............................................. 1
21 400306 Screw, Hex, 3/8”-24 x 2” .......................................... 1
22 650604 Link, RC-41 Master ................................................. 1
23 655399 Chain, RC-41 x 62, Includes Item 22 ...................... 1
24 458013 Ring, Retaining, 3/4” External ................................. 1
25 499074 Washer, Flat
49/64” ID x 1-5/16” OD x 3/64” Thick .................... 2
26 655668 Sprocket, Drive, Includes Item 27 ........................... 1
27 650572 Bearing, Oilite, AA-1043-9 ....................................... 2
28 655678 Clutch ...................................................................... 1
29 655670 Guard ...................................................................... 1
30 400106 Screw, Hex, 1/4”-20 x 5/8” ....................................... 3
31 655416 Bracket, Guard ........................................................ 1
32 655425 Rod, Control ............................................................ 1
Note A: These items are part of the Edger Assembly. See pages 16
and 17.
Item Part Description Qty.
No. No.
Item Part Description Qty.
No. No.
PARTS LISTS
