Adjust Values Menu
Use the built-in editor to adjust any of these values. The default values are shown
Test Number: the test reference number between 1 and 30000, it is automatically incremented
after each test.
Pass B1 > 25.0 %g: pass threshold for the 1
st
brake type (normally ’Service’)
Pass B1 > 25.0 %g: pass threshold for the 2
nd
brake type (normally ’Secondary’)
Pass B1 > 25.0 %g: pass threshold for the 3rd brake type (normally ’Parking’)
Pass B1 > 25.0 %g: pass threshold for the 4
th
brake type
Trig at 10.0 %g: the deceleration threshold for start of braking
Stop at 10.0 %g: the deceleration threshold for end of braking
Trig hold 0.50 sec: the minimum time the deceleration must be sustained over the start threshold
to be a true start of deceleration. The true start time is the start of this time.
Stop hold 0.20 sec: the minimum time the deceleration must be sustained below the stop
threshold to be a true end of deceleration. The true stop time is the start of this time.
End Delay 2.5 s: delay before measuring the stop point slope gradient. Only if ‘Slope at Stop’ has
been selected.
Peak over 0.20 sec: the minimum time the peak reading has to be sustained.
Dive 5.0 deg/g: compensation for the tilt of the vehicle (in degrees tilt per g of deceleration)
caused by the movement of its suspension as it decelerates
PFT trig 20.0 kgF: trigger point for Pedal Force Transducer in kg force. Only if PFT is enabled in
settings.
2.5V PFT 100.0 kgF: PFT calibration, force required for 2.5 Volts output from PFT
0.0V PFT 0.0 kgF: PFT calibration, force required for 0.0 Volts output from PFT
Card Folder 0: the next SD memory card folder to be used (in range 0 to 999). Only if the SD
card feature has been enabled by the factory.
Filter type 2: the amount of smoothing applied to the readings for the graphs. Zero means no
smoothing is applied.
Lifetime 24 hr: the length of time from the last brake test that the pass/fail lights will remain
illuminated. Set to 0 to disable the pass/fail lights.
• Save Changes: save the changes made.
• Reset ALL: revert to default values (shown above), then need to Save Changes too!
• No changes: revert to the previous values
