Simret 4000 Instructions, Issue 10, Jan 2011
© 1994-2011, Turnkey Instruments Ltd. Page 10 of 17
can be adjusted if required via the Adjust Values Menu. The applied force at which the PFT
triggers the start of braking is also shown in this menu
To use as a simple ON/OFF trigger pad, just set the measure Pedal Force setting off. The PFT
will then use a fixed setting of about 5 kgF to trigger the start and the Gradient Measurement
mode displays ‘BRAKE ON’ when a force greater than the internal trigger setting is applied.
The instrument will sense if a non-Bluetooth Pedal Pad is connected to the DIN socket. In this
case the instrument will use the connected Pedal Pad (and not attempt to pair) either as an
analog pedal force transducer or as a simple on/off trigger switch. The Gradient
Measurement mode will display either the applied pedal force or ‘BRAKE ON’ as above
(providing external trigger is enabled). Note that the instrument will not attempt to zero an
analog PFT connected in this manner and you must adjust its zero manually in the Adjust
Values menu.
Setup Instrument Menu
The Editor PIN may be required to access this menu
Adjust Values: single-click to select the Adjust Values menu.
Change Settings: single-click to select the Change Settings menu.
Setup Bluetooth: single-click to select the Setup Bluetooth menu (Bluetooth must be ON).
Trim Zeros: single-click to accurately trim the zero readings of the instrument by following the on
screen instructions. Any flat surface may be used, it need not be horizontal.
Erase all Tests: single-click to erase all the tests in the instrument’s memory, regardless of
whether marked for erase or not. You will be prompted to confirm
Set Time and Date: single-click to set the time and date by following the on screen instructions
Adjust Contrast: single-click and ►◄ to adjust the contrast of the display
Adjust Backlight: single-click and ►◄ to adjust the brightness of the backlight. The brighter it
is the more battery power will be used. To conserve power, the light turns off if there has been
no input for about 2 minutes.
Defragment Memory: single-click to confirm that the memory is fully defragmented and all free
space is available for use.
Format SD Card: single-click to format the SD Card to make it visible to a personal computer
(FAT16 file system). Sets all the Folder names to FFFFFnnn.TKI (nnn=000 to 999, hidden
file attribute) but does not overwrite previously stored data. Folders are in the BACKUP
subdirectory of the TURNKEY root directory
Configure Printer: single-click to configure printer fonts and timeouts. Also resets the Bluetooth
to its factory defaults in case of problems.
Calibration Report: single-click to print calibration report.
User PIN: single-click to change the PIN required to use the instrument. Make a note of it! (5424)
Editor PIN: single-click to change the PIN required to set-up the instrument. Make a note of it!
(4748)
Main Menu: single-click to return to Main Menu.
