STEP 1:
Needed:
Item No. Qty.
3 1
7 6
The Kobuki Base has 6 locations where the ~1.5in Standoffs are fastened.
Fasten the Standoffs to the Kobuki Base
in the locations illustrated by the drawing.
Done properly, the base should now
resemble the picture below:
TurtleBot 2 Assembly Instructions
IHE-2700-000C-0000
Page 4/9
