STEP 2:

Needed:

Item No. Qty

1 6

4 1

12 1

Place Disc1 on top of the standoffs, with the bar code facing down. Orient and

fasten using 6 M4 screws. Refer to the picture for reference.

TurtleBot 2 Assembly Instructions

IHE-2700-000C-0000

Page 5/9
