TurtleBot 2 - Step 5: Attach Disc 3; Mount Disc 3 with 8 in Standoffs

Step 5
Needed:
Item No. Qty.
1 4
6 1
9 4
Fasten the 4 8in Standoffs to the threads protruding from Disc 2.
Place Disc 3 atop the 4 standoffs, orient c, and fasten with 4 M4 screws.
TurtleBot 2 Assembly Instructions
IHE-2700-000C-0000
Page 8/9
