66
screw
tube A(Length
40mm)
X2
screw
tube B(Length
28mm)
X2
4.Put the front handle wire through the
middle of the 100 square cylinder;
1.Door thickness 41-50mm with screw tube A
2.Door thickness 30-40mm with screw tube B
Door lock installation tutorial
5.Screw the stud into the front hand full
tooth screw and tighten it with pliers;
5
The correct way to install the square
holes on the lock lever
Right
Wrong
Figure 2
Door opening direction
3.Installation
Please follow the below steps to install the lock
(1)As Figure 1:
Adjust the back distance of the lock body as required(60 or 70mm).When
adjusting the back distance, hold the square hole on the lock lever with
your hand and push it to the edge of the lock lever, front and rear the hole
must be horizontal.
Latch
Screw:ST4X21( mm)
(2)As Figure2:
Fix the latch with 2 screws.
60mm
70mm
Latch
Latch
Latch
Figure 1
2.1 Adjusting handle
Adjust the direction of the handle according to the opening direction of the
door. If necessary, adjust as shown in the figure Figure 1; Turn the handle
180 degrees.
Figure 1
Door opening direction
2.Door Opening Direction
(1)Right handle opening
Right inwards
Inside
Outside
Right outwards
Inside
Outside
(2)Left handle opening
Left inwards
Inside
Outside
Left outwards
Inside
Outside
4
Measuring door dimensions
strike box
strike plate
screw ST3.5*20(mm)
figure 1
1
figure 2
(1)As Figure 1:
Fix the strike plate with 2 screws on the
door frame.
(2)As Figure 2:
“Reset” button.(Press and hold for 5 seconds)
1.Measure the Door Size
Make sure door thickness is 30mm-50mm, door hole diameter is Ф54mm,
measure backset size is 60/70mm with the deadbolt.
TIPS:
1.Available door thickness 30mm-50mm. If the door is over this range.
Please contact us for more information.
2.Please select the correct accessories according to your door thickness.
3
