Components Packed in carton 3
Components Packed in carton 4
(3) Side Rails
x2
(4)
(5)
(9)
(12)
(10)
(7) (8)
x2
Page 4 of 16
TV INSTALLATION KIT
HARDWARE FOR ASSEMBLING THE BED & FITTING THE TV - PACKED IN CARTON 2
Allen Key (4mm)
Allen Key (2.5mm)
(M6x12mm)
Counter-Sunk Screws
Counter-Sunk Screws
(M4x12mm)
Cable ClipsPower Lead - 3 metre Cable Ties
S x1 W x3V x3
CABLES & ACCESSORIES FOR TV INSTALLATION
Y x1
Screw-Washer Sets
(M8x25mm)
Use 5mm Allen Key (D)
Remote Control
a x2
b x2
Spacer Rails for
Lift Mechanism
‘U’ Shape Cross Bar
Lift Mechanism - LH
Lift Mechanism - RH
Gas Lift Pistons
Metal Slat Frame for Double or King Size
(17)
(14)
Metal Slat Frame for Super King Size
Fabric Base Cover
Fabric Hand Strap
x1
x1
x1
x1
x1
x1
x1
x2
