TVLogic LVM-240W User Manual

72
<FRONT>
LVM-240W
<REAR>
TALLY
ANALOG INPUT
SDI INPUT SELECT
UNDER SCAN
ASPECT
MARKER
H/V DELAY
STAND BY
ENTER
UP / CONTRAST
DOWN / BRIGHT
MENU
CHROMA/PHASE
BLUE ONLY / MONO
REMOTE
DVI-I IN / FACTORY PGM
CVBS1 / Y / G / S-Y
CVBS2 / Pb / B
CVBS3 / Pr / R / S-C
SDI IN-A
SDI OUT-A
SDI IN-B
SDI OUT-B
DC 24V
~AC IN
LVM-170W (G) / 230W / 240W
