TVS Apache RTR 200 4V - Vehicle Front & Rear Components

15
15
LOCATION OF PARTS - VEHICLE FRONT & REAR
FRONT
1. Turn signal lamp front L
2. Head lamp assembly
3. Oil cooler
4. Crash guard
5. Position lamps
6. Turn signal lamp front R
REAR
1. Turn signal lamp rear R
2. Reflex reflector
3. Number plate lamp
4. Turn signal lamp rear L
5. Tail lamp assembly
6. Pillion handle
License plates are mandatory accessory will be charged extra
1
2
3
4
6
5
2
1
3
4
6
5
