16
CONTROL KEY
Your TVS Apache RTR 200 4V comes with a pair of
identical control keys. These keys are to operate
ignition cum steering lock, fuel tank cap and seat lock.
IGNITION CUM STEERING LOCK
The ignition cum steering lock enables and disables
the electrical circuit and steering lock. The three
positions of the switch are described below.
1. ‘OFF’ position
All electrical circuits are deactivated. The key can be
removed from the lock.
2. ‘ON’ position
All electrical circuits are activated. The instrument
cluster and warning lights performs self-diagnostic
cycle. Engine can be started. Control key cannot be
taken out from the lock.
3. ‘LOCK’ position
Your TVS Apache RTR 200 4V steering can be locked
in both ‘left’ and ‘right’ directions.
Turn the handlebar to the ‘left’ or ‘right’. Press the key
‘IN’ and rotate it to the ‘LOCK’ position from ‘OFF’
position. All the electrical circuits are deactivated
and the steering is locked. The control key can be
removed from the lock.
Insert the control key into the lock and press the key
‘IN‘ and turn it to ‘OFF’ or ‘ON’ position to unlock the
steering.
When the ignition is turned ON with the engine kill
switch ON condition, priming noise of pump may be
heard which is absolutely normal.
Frequent switch ‘OFF & ON’ of ignition to be avoided.
After ignition key reset, there may be a delay in start of
vehicle for couple of seconds.
