TVS Apache RTR 200 4V - Page 69

56
ADJUSTMENTS
CLUTCH LEVER - ADJUSTMENT
TVS Apache RTR 200 4V comes with an adjustable
clutch lever. There are three positions provided for
you to adjust the lever to suit your palm size. The
lever can be adjusted by adjusting the “position
adjuster” (A) provided in the knob itself. Position-1
is the closest to handle bar grip and Position-3 is the
farthest.
To adjust the lever position, push the lever forward
and rotate the “position adjuster” to any of the three
positions by aligning the ‘arrow mark’ on the lever to
the number provided on the adjuster.
FRONT BRAKE LEVER - ADJUSTMENT
TVS Apache RTR 200 4V comes with an adjustable
front brake lever. There are three positions provided
for you to adjust the lever to suit your palm size.
The lever can be adjusted by adjusting the “position
adjuster” (B) provided in the knob itself. Position-1 is
the closest to handle bar grip and Position-3 is the
farthest.
To adjust the lever position, push the lever forward
and rotate the “position adjuster” to any of the three
positions by aligning the ‘arrow mark’ on the lever to
the number provided on the adjuster.
A
B
