PERIODIC MAINTENANCE SCHEDULE (months or km whichever occurs earlier)
R - Replace; I - Inspect; T - Top up; C - Clean; A - Adjust; DR - Drain; L - Lubricate; TI - Tighten; S - Set
1
Inspect for damage
2
Clean the cover with air. Lubricate kick starter with Bechem grease
contd...
Item
Service
km
Period from the date of sale
In free service After free service
Remarks
1st
500 - 750
2 months
2nd
2500 - 3000
4 months
3rd
5000 - 6000
8 months
4th
8500 - 9000
12 months
Every
3000 km
4 months
Every
6000 km
8 months
Engine oil R I & T R I & T I & T R
Oil filter (strainer) C – C – – C
Transmission oil R I & T R I & T I & T R
Spark plug I – – – – –
Inspect, Clean and adjust if re-
quired, Replace every 12000 km
Air cleaner element I – – – – – Replace every 12000 km
Air cleaner oil collection tubes – I & DR I & DR I & DR I & DR – Drain oil if necessary
CVT filter element
1
– – I & C – – I & C Replace every 12000 km
Tappet clearance I – I & A – – I & A
Inspect for any noise / starting
trouble and adjust if required
Drive belt and CVT rollers – – – – – – Replace every 24000 km
Cover variator
2
– – I, C & L – – I, C & L
Clutch shoe – – – – – – Replace every 24000 km
Hose fuel – – – – – – Replace every 3 years
Front and rear suspension I I I I I – Inspect for proper functioning

TVS Jupiter ZX Specifications

General

Engine Capacity	109.7 cc
Front Brake	Drum
Rear Brake	Drum
Kerb Weight	109 kg
Front Suspension	Telescopic
Tyre Type	Tubeless
Engine Type	Single Cylinder, 4 Stroke, Air Cooled
Transmission	CVT
Tyre Size (Front)	90/90-12
Tyre Size (Rear)	90/90-12
Length	1834 mm
Height	1115 mm
Seat Height	765 mm
Ground Clearance	150 mm
Wheelbase	1275 mm
Maximum Torque	8.4 Nm @ 5000 rpm
Brakes	Drum
Rear Suspension	Hydraulic
Starting Method	Electric Start
Max Torque	8.4 Nm @ 5000 rpm
Wheel Size	12 inches
