TVS Jupiter ZX User Manual

90
REAR SHOCK ABSORBERS
TVS Jupiter ZX is provided with 3 step adjustable
rear shock absorbers to meet different road and load.
There are 3 notches for adjusting spring load.
If the spring is adjusted to the minimum notch, then
the shock absorber will be softer which is good for
light loads. If the spring is adjusted to maximum
notch, then it will be stiffer which is good for heavy
loads.
Adjust the spring pre-load by shifting the adjuster
to the required notch according to the different load
conditions. The more you compress the spring, the
suspension becomes more stiff.
SOFTHARD

TVS Jupiter ZX Specifications

General

Engine Capacity	109.7 cc
Front Brake	Drum
Rear Brake	Drum
Kerb Weight	109 kg
Front Suspension	Telescopic
Tyre Type	Tubeless
Engine Type	Single Cylinder, 4 Stroke, Air Cooled
Transmission	CVT
Tyre Size (Front)	90/90-12
Tyre Size (Rear)	90/90-12
Length	1834 mm
Height	1115 mm
Seat Height	765 mm
Ground Clearance	150 mm
Wheelbase	1275 mm
Maximum Torque	8.4 Nm @ 5000 rpm
Brakes	Drum
Rear Suspension	Hydraulic
Starting Method	Electric Start
Max Torque	8.4 Nm @ 5000 rpm
Wheel Size	12 inches
