TVS NEO Series User Manual

SPECIFICATIONS
SPECIFICATIONS
1
1
GLOBAL DIMENSIONS
NX XR & X3i
Total length
Total width (handlebars) 665 mm 662 mm
Total height 1090 mm 1360 mm
Seat height
Ground clearance 150 mm 140 mm
biodegradability
wheelbase 1260 mm 1245 mm
Unloaded weight 100 kg 96 Kg
Payload 132 Kg 130 Kg
ENGINE
NX XR & X3i
Type
Bore x stroke
Piston displacement 109,7 cc 109,7 cc
Compression ratio
Carburetor VM 17 UCAL
Single cylinder 4 stroke air
cooled engine
53,5 x 48,8 mm
9,3:1
1940 mm
760 mm
18°
GLOBAL DIMENSIONS

TVS NEO Series Specifications

General

Engine Type	Single Cylinder, 4 Stroke, Air Cooled
Displacement	109.7 cc
Tyre Type	Tubeless
Transmission	4 Speed
Fuel Tank Capacity	10 liters
Brakes	Drum
Front Suspension	Telescopic
Rear Suspension	Hydraulic Shock Absorber
