28
3. Turn signal lamp switch
When the turn signal switch is moved to left ’ ‘
or right ‘ ‘, the corresponding turn signal lamps
flashes. To stop flashing, push the switch in.
4. Clutch lever
Press the lever towards grip to disengage the drive.
It is used to disengage the clutch while shifting the
gears.
5. Pass-by switch
Press the switch to flash the head lamp. It is used to
give signal to the vehicles coming from the opposite
direction while overtaking other vehicles during day.
The head lamp glows automatically once the engine
is started. If the head lamp is glowing in ‘Low’ beam,
on pressing the switch, the head lamp ‘High’ beam
also glows along with the ‘Low’ beam.
Pass by system will not work if the head lamp is glowing
in ‘High’ beam.
Use appropriate head lamp beam ‘high / low’ as per the
traffic and road conditions for your safety and to avoid
inconvenience to other riders.
It is strongly recommended to ride the vehicle in ‘low’
beam during day.
Warning
If the head lamp is already glowing in ‘High’ beam,
the pass-by system will not work.
6. Head lamp high / low beam switch
The head lamp low beam glows automatically once
the ignition switch is turned ‘ON’. Only the head lamp
beam (high/low) can be controlled with the beam
control switch.
Press the top end of switch for ‘High’ beam ’ ‘ and
bottom end for ‘Low’ beam ‘ ‘.
Failure to switch the turn signal lamp ‘ON’ or ‘OFF’ at the
right time may lead to an accident.
