12. Fuel gauge
Digital bars indicates the approximate quantity of
fuel available in the fuel tank. There are eight bars to
indicate the quantity of fuel available in the fuel tank.
All the eight bars will be displayed when the fuel in
the tank reaches above 10.5 liters approximately (full
tank).
Low fuel indication (serial no. 5) starts blinking when
the fuel reaches to the minimum safe level 2.5 liters
approximately. Refill the fuel immediately. Once the
fuel level reaches 1.8 liters approximately, no bar will
be visible and low fuel indication (serial no. 5) glows
continuously.
Before turning the ignition key to ‘ON’ position, ensure
the availability of adequate fuel in the tank. That is ‘LOW
FUEL INDICATION’ shall not come ‘ON’, before the start
of the vehicle.
To avoid dry run of fuel pump, never run vehicle
beyond 5 km, after ‘LOW FUEL INDICATION’ is turned
‘ON’.
If all the fuel level bars in the cluster are blinking
and an error message ‘CHECK FUEL SENSOR’
blinks at bottom, contact nearest TVS Motor
Company Authorised Main Dealer / Authorised
Dealer.
When the fuel reaches half tank (6.5 liters approx.)
the fuel gauge displays only four bars as shown.
The fuel gauge shows only single bar when the fuel
reaches safe fuel level (3.5 liters approx.).
