32
6. Neutral indicator lamp ( )
Glows when the vehicle is in neutral and goes ‘OFF’
if the gear is shifted from neutral.
7. High beam indicator lamp ( )
Glows when the head lamp is activated in high beam.
8. ABS warning lamp ( )
ABS warning lamp blinks when the ignition key is
turned ‘ON’ and speedometer performing self check.
This lamp goes ‘OFF’ once the vehicle reaches
7 km/h speed and above.
If this lamp glows continuously then have your
vehicle checked at TVS Motor Company Authorised
Main Dealer / Authorised Dealer (refer page no. 14
for more details).
9. Malfunction indicator lamp ( )
Malfunction indicator lamp (MIL) ‘ ’ is activated
whenever the ignition is turned ‘ON’, till the engine
is started. It will go ‘OFF’ once the engine is started.
If the battery is disconnected and reconnected during
service, you may need to reset the time as explained in
page no. 44.
The ABS warning lamp will blink whenever the vehicle
speed is less than 7 km/h which is normal. It also
indicates that the ABS is working fine.
If this lamp glows continuously even after starting
the engine, it indicates that there may be an error
in the system. Immediately contact the nearest
TVS Motor Company Authorised Main Dealer /
Authorised Dealer.
10. Turn signal indicator left ( )
Flashes when the left side turn signal indication is
activated.
11. Digital clock
Indicates the time in 12 or 24 hour time format as
per user’s preferred setting. Refer page no. 44 for
changing the time format between 12 hour and 24
hour.
