103
CHASSIS
Overall length : 2070 mm
Overall width : 785 mm
Overall height : 1028 mm
Ground clearance : 180 mm (unladen)
Wheel base : 1326 mm
Kerb weight : 123 kg
(with tool kit & 90% of fuel)
Pay load : 130 kg
Maximum laden weight : 253 kg
Steering angle : 80°
Caster angle : 25.6°
Frame : Single cradle tubular frame
Front suspension : Telescopic oil damped
Rear suspension : 5 step adjustable,
gas charged hydraulic shock
with swing arm
Trail length : 85 mm
TYRE
Front tyre : 80/100-17 M/C 46P Tubeless
Rear tyre : 100/90-17 M/C 55P Tubeless
Tyre pressure
Front : 1.75 kg/cm
2
(25 PSI)
Rear - Solo : 1.97 kg/cm
2
(28 PSI)
Rear - Pillion : 2.25 kg/cm
2
(32 PSI)
BRAKES
Front : Hand operated, 240 mm petal disc
: Hand operated, 130 mm dia drum
Rear : Foot operated, 130 mm dia drum
ELECTRICAL
Ignition system : ECU - Electronic Control Unit
Spark plug : BOSCH UR5KCW
Spark plug gap : 0.9 ~ 1.0 mm
ISG magneto : ISG Starter generator 12V, 160W
Battery : 12V, 4 Ah MF
Headlamp : 12V, LED, 10W Max
Tail / brake lamp : 12V LED, 0.3W/2.5W
Turn signal lamps bulb : 12V, 10W x 4
Number plate lamp bulb: 12V, 5W x 1
