55
** The fuel tank is not a measuring instrument and the capacity
of the fuel tank may slightly vary from the indicated capacity.
Avoid spilling of fuel on the hot engine.
Never refill fuel near open flame. Do not smoke while
refueling.
Do not use cell phones while refueling.
FUEL TANK** CAP
Flush type fuel tank cap (1) is provided in TVS Raider
125. To open the fuel tank cap, lift the protection lid
(2), insert the control key into the lock and turn it
in clockwise and lift the cap. Press the cap back to
its original position, rotate the key in anti-clockwise
direction and lock the cap. Close the lid at the end.
To avoid accumulation of water in the fuel tank, a
small drain hole and a pipe is provided in the fuel tank
lid cavity so that the water entering through the lid is
drained out through a hose.
1
2
