ENGINE CUM TRANSMISSION OIL LEVEL
Check the engine cum transmission oil level
periodically.
1. Place the vehicle on centre stand on a flat surface.
Wipe-off the surroundings of gauge oil level.
2. Remove the gauge oil level and wipe it clean.
3. Fix the gauge back to its mounting hole. Do not
thread in.
4. Take out the gauge and check the oil level.
5. The oil level should be between minimum and
maximum level marks of the gauge as shown in
the figure.
6. If the oil level is less than the minimum level, add
TVS TRU4 PREMIUM oil ((SAE 10W30 API-SL
JASO MA2) upto the maximum level mark.
7. Wipe out the oil traces with a clean cloth to
prevent dust accumulation and assemble back
the gauge oil level.
If the vehicle is driven with less engine cum transmission
oil, the engine components will be severely damaged.
Check the oil level as per the schedule to avoid costly
damage.
Do not fill excess oil as it may cause the oil leak. Always
use ‘TVS TRU4 PREMIUM (SAE 10W30 API-SL JASO
MA2)’.
Maximum
Minimum
