83
Front brake (Drum type)
1. Measure the free play of the front brake lever at
the lever end as shown in the figure.
2. The free play of the brake lever before the
engagement of brake should be between
15 ~ 20 mm.
Brakes are items of personal safety and should always
be maintained in proper condition.
1
I
Since the vehicle is fitted with Synchronised Braking
Technology (SBT) adjust the brakes with additional
care. If not it may result in brakes not working
properly.
Please contact TVS Motor Company Authorised Main
Dealer / Authorised Dealer for any further assistance.
15 ~ 20 mm
