Ensure the proper seating of seat assembly in the frame
after reassembling.
For removing :
1. Insert the control key into the seat lock and rotate
it in clockwise direction.
2. Take out the seat assembly by lifting it from the
rear end and gently tapping it on the front end.
For re-fixing :
1. Assemble the seat assembly in the frame and
push it forward.
2. Gently press at the rear end until you hear a click
sound from the lock and take out the control key.
SEAT LOCK
Seat lock is provided at the tail end of the vehicle for
the removal of seat assembly and there by accessing
the tool kit and first aid kit. Follow the procedure given
below for removing and re-fixing the seat assembly.
