TECHNICAL SPECIFICATIONS
MANUFACTURER : TVS MOTOR COMPANY LIMITED
P.B. No 4, Harita, Hosur - 635 109, India.
ENGINE
Type : Single Cylinder, 4 stroke, air
cooled spark ignition engine
Cylinder bore : 53.5 mm
Stroke : 48.8 mm
Piston displacement : 109.7 cc
Compression ratio : 10.0 : 1
Air filter : Paper filter element
Lubrication system : Wet sump lubrication
Maximum power in kW : 6.03 kW @ 7350 rpm
Maximum torque in Nm : 8.7 Nm @ 4500 rpm
Maximum speed : Around 90 km/h
Engine idling rpm : 1500 ± 150 rpm (under warm
condition)
Starting system : Electric starter / Kick starter
Emission norms : BS VI
TRANSMISSION
Clutch : Wet - Multi plate type
Transmission : 4 speed constant mesh
Gear shift pattern : All up, heel-toe shift
Primary transmission : Spur gears
Secondary transmission : Chain and sprockets
GEAR RATIOS
I Gear : 3.273
II Gear : 1.765
III gear : 1.238
IV gear : 0.958
Primary reduction : 3.722
Secondary reduction : 2.857
