twintex TP-3020 - TP Series Model Specifications (Table 2)

- 3 -
Table 2
Model
TP-3010
TP-6005
TP-3020
TP-6010
Constant voltage operation
Line regulation
≤0.01%+5mV
≤0.01%+5mV
≤0.01%+10mV
≤0.01%+5mV
Load regulation ≤0.02%+5mV ≤0.02%+5mV ≤0.02%+10mV ≤0.02%+5mV
Ripple & Noise
≤3mVrms, 5Hz~1MHz
Constant current operation
Line regulation
≤0.2%+3mA
Load regulation ≤0.2%+3mA (I≤3A)
≤0.2%+5mA (I>3A)
≤0.2%+15mA (I≥10A)
Ripple & Noise ≤3mArms (I≤3A)
≤10mArms (I>3A)
Display
Voltmeter
3 digits LED display
Ammeter 3 digits LED display
Resolution
100mV/10mA
Accuracy Real voltage and current output: ±(1% reading+2 digits)
Preset voltage and current: ±(1% reading+8 digits)
General
Operating environment 0℃~40℃, ≤80%RH
Storage environment -10℃~70℃, ≤70%RH
Power source AC110V/220V±10%, 50/60Hz
Accessories Power cord x1, Operation manual x1, Test lead x1
Dimension 255Wx155Hx370Dmm 255Wx155Hx330Dmm
In purpose of product improvement, specifications are subject to change without prior notice.
