TWISTERTRIMMER.COM
MACHINE OVERVIEW
pg | 5
Fig. 1
TUMBLER GUARD
TUMBLER BELT COVER
BLADE ADJUSTMENT CLICKER
TUMBLER MOTOR
CONTROL PANEL
BLADE MOTOR
BLADE BELT COVER
BLADE ADJUSTMENT CLICKER
BELT COVER SCREWS
BELT COVER SCREWS
HOPPER BOLTS*
*Hopper bolts are located on both sides of the T2.
