TXR 325D - Duty Cycle and Physical Characteristics

Standard Frequency Series Generators
Operation
18
M-2008-7-14
6.4 PHYSICAL CHARACTERISTICS
COMPONENT
DIMENSIONS
WEIGHT
Length Width Height
STANDARD CONTROL CONSOLES
RAD Control
Consoles
TXR 325 D
457 mm
18 in
305 mm
12 in
941 mm
37 in
61 kg
135 lbs
TXR 325 M
457 mm
18 in
305 mm
12 in
941 mm
37 in
61 kg
135 lbs
TXR 525 SFQ
457 mm
18 in
305 mm
12 in
941 mm
37 in
62 kg
137 lbs
HIGH VOLTAGE TRANSFORMERS
High Voltage
Transformer
TXR 325-1
559 mm
22 in
508 mm
20 in
351 mm
13.8 in
118 kg
260 lbs
TXR 625-1
559 mm
22 in
508 mm
20 in
351 mm
13.8 in
120 kg
265 lbs
