INSTRUMENT AND RELATED PARTS
Rear Window
The rear window is fitted with central handle for opening.
To open, pull handle upwards and push forward
Doors
The doors are provided with key locks.
To open from the outside, when unlocked, depress the push button and pull the door towards you.
To open from inside, push the lever downwards in the direction indicated by the arrow.
To open, pull handle upwards and push forward
When opened it is held in place by two dampers.
90
Side Window
The side window is fitted with central handle
for opening. When opened it is held in place
by holder.
To open the side window, pull the handle
in the direction indicated by the arrow and
push outwards.
Working Lamps (Front and Rear)
The working lamps are located on the cab roof
(two in the front and two in the rear) .
They are switched on by means of the special
Switches on the roof console.
