TYM T264 - Page 149

SECTION 2. SPECIFICATIONS
1) GEAR PUMP
MODEL T264HST
Delivery (cc/rev) 5.0
Pump performance
180
(kgf/cm
2
)
1000 rpm 4.4LPM
1800 rpm 8.1LPM
2600 rpm 11.7LPM
Maximum pressure (kgf/cm
2
) 230
Rated operation speed (rpm) 500~3000
Rotation direction C.C.W as viewed from shaft end
2. Power steering valve Unit(orbitrol)
MODEL T264HST
Displacement (cc/rev) 63
Rated flow (ℓ/min) 16
Maximum system pressure (kgf/cm
2
) 125
Max. back pressure (kgf/cm
2
) 20
Max. temperature(℃) 95
Input torque (kgf.m) 0.1~0.2
Inlet relief pressure setting (kgf/cm
2
) 110~115 (at 12 ℓ/min)
Recommended filter Nominal 10 micron
3. OIL TANK
MODEL T264HST
TANK TRANS MISSION
Fluid volume (ℓ) 14
Fluid THF500
8-2
