8. FILTER
-30 ∼130℃
DONAX TD or RPM THF 500Applicable oil
11000㎠Filtration area
Working oil temperature
(℃)
25 ㎛Filtration density
57Rated flow rate(ℓ/min.)
T390(T400)/T430(T450)/T431(T451)Model
2) Line filter
10 micronFiltration density (mm)
32Rated flow(ℓ/min.)
3,276 meshFiltration area(㎠)
-Working oil temperature
THF500Applicable oil
9-43
8.3 REPLACEMENT
Check the O-rings for damage or deformation
and replace defective ones.When installing the
filters,be sure to install the O-rings properly
with grease applied.
1.Filter
2.O-ring
3.Bolt
4.Filter
5.Cartridge
6.Bracket
7.Bolt(S)
9.Washer
10.Bolt(S)
11.O-ring
12.Cylinder case
13.Rear transmission case
8.1 GENERAL DESCRIPTION
The tractor is equipped with two oil filters:
suction filter(1) and line filter(4),for better
filtration.
8.2 SPECIFICATIONS
1)Suction filter
Fig. 9-67 Filter
