SECTION 2. SPECIFICATIONS
1°± 1°Caster
3°± 1°Camber
52˚
Φ75
Φ50
75X80X30
50X55X20
Φ80
Front wheel steering angles
Housing (R) Diameter (mm)
Housing (F) Diameter (mm)
Pivot metal (R) bush (mm)
Pivot metal (F) bush (mm)
Pivot metal (R) bore (mm)
Φ55Pivot metal (F) bore (mm)Front axle
2~6Toe-in (mm)Wheel alignment
3510/4110/T400/T450/T451
6-2
Fig.6-2
