Page #211 background imageLoading...
Page #211 background image
9 cc/min
A and B port leak
Oil temperature:50℃(122℉)
Under a load of 100Kgf/㎠
THF 500Recommended fluid
210Maximum pressure(Kgf/㎠)
-20℃~80℃Operating temperature range
45LPMMaximum flow (ℓ/min)
3. SPECIFICATIONS
9-36
3.1 HYDRAULIC CIRCUIT
Fig. 9-69 Remote hydraulic pump
P:From pump
T:To tank
A:High pressure port
B: Return port
