SPECIFICATIONS
Model: T454/T554
ENGINE
4 Cycle, Inline, Water-cooled Diesel
Model : T454(4TNV88C-KKTF)
: T554(4TNV86CT-KKTF)
No. of cylinders : 4
Displacement : T454(2,190)Liters
: T554(2,091)Liters
Bore : T454(88mm(3.5in)
: T554(86mm(3.4in)
Stroke : T454,T554(90mm(3.5in)
Compression Ratio : 19.1 / 19.2
Rated power (kW/rpm) : T454 – 34.3/2800 rpm
T554 – 41.1/2800 rpm
(Manufacturing rating)
Rated Speed : 2,800
rpm
High idle rpm : 2,950±10RPM
Low idle rpm : 950 ±10RPM
Fuel injection pump : Common Rail.
Cylinder sleeve : -
Air Cleaner : Dry Filter element,
paper element filtering type.
DPF: Horizontal External type
Firing order : 1-3-4-2-1
Accelerator : Hand & Foot Accelerator
ELECTRICAL STARTING AND LIGHTING
Battery Capacity : 12 Volt 80AH
Starter : Solenoid Engaged.
Key Start with interlock,
Neutral switch
Alternator : 12V 55A
Instrumentation : Water Temperature Gauge,
Taco meter, Hour meter,
Electrical fuel level gauge.
Lighting: Head lamps, side indicators,
Rear parking brake
& indicator light
On dash board indicators
for battery charging, turn
signal, PTO signal, Engine
oil pressure, Preheat signal.
CLUTCH
Type : Diaphragm
Outer dia. X Inner dia. : Ф260XФ180
TRANSMISSION
Type : synchro mesh
No. of gears :16 forward,
16 reverse speeds
with high and low
selection lever with
Differential Lock
STEERING : Hydraulic power
(Power steering)
POWER TAKE OFF
Rear mounted : 6 splines
Diameter : 1⅜ in.(35mm)
Standard PTO : ①540
BRAKES
Foot operated, independent with provision of
inter lock for simultaneous operation. A foot
brake is fitted for parking.
Disc Diameter :Φ183mm(Φin)
Number of lining :4 each side
Total brake thickness : 21.1㎜(in.)
HYDRAULIC SYSTEM
Independent fully”Live”hydraulic pump
and separate reservoir. Position controls with
isolating & response control
Piston and cylinder Lift 1503 kgf
(at lower link top end)
Pump output :
Main : 15.0 cc/rev (38.3 ℓ/min)
Power Steering : 7.2 cc/rev (18.8 ℓ/min)
Delivery(93% efficiency) : liter(cu.in)mm at
2800rpm
3 point linkage : USA -Category 1
EU-
Category 2
adjustable outside stabilizer
