Roof hatch( if equipped)
Ventilation-push the latch towards the front of the tractor
and then push the hatch up.
Emergency Exit-Push firmly upwards to release the
support struts from the lower retainer clips.
Circulation diffuses
With the circulation vent set in any position
outside Air will still be pulled into the cab.
Cab air filters remove dust in the air,but are not capable of removing chemicals used in
Cab Air intake filter
The《Paper》 filter is not suitable for the treatment of
pesticides and so must be replaced by an《ACTIVE CARBON》
FILTER available optionally.Once the pesticide treatment is
finished, it is necessary to once again replace the “ACTIVE
CARBON” filter with the paper filter, since this is the only type
suited for filtering foreign particles from the air.
Optional ACTIVE CARBONFILTER is informed to parts Catalogue
crops or in weed control.Many chemicals used for these purposes are toxic when
improperly used .and can be hazardous to operators and others in the area.Follow the
instructions of manufacturers of both the equipment and the chemicals regarding
prohibition of dust or spray ,personal hygiene practices,and other precautions noted by the
manufacturers.
Radio cassette( If equipped)
For operation refer to the radio manufacturers instructions.
Ash tray
Located at left side of side window in cabin.
Cup Holder
Located at right side of side window in cabin and
Put the bottles and Personal materials.
Connector wire for I-POD (If equipped)
You can connect this wire as MP3 or I-POD Player.
89
Connector wire for I-POD
Warning
