SPECIFICATIONS
Model: T603
ENGINE
Four strokes, Direct injection, water-cooled
Diesel Engine.
Model : C2.2T (404C - 22T)
No. of cylinders : 4
Swept Volume : 2.216 Liter 5(135 in³)
Bore : 84 mm (3.3 in)
Stroke : 100 mm (3.9 in)
Compression Ratio : 22.4:1
Horse Power (PS) : 58/2600 rpm
(Manufacturing rating)
Rated Speed : 2,600 rpm
Fuel injection pump : Bosch automotive systems
Cylinder sleeve : Dry
Air Cleaner : Dry Filter element,
paper element filtering type.
Exhaust Muffler : Horizontal Round.
Firing order : 1-3-4-2
Accelerator : Hand & Foot Accelerator
CLUTCH
Type : Dry single
Outer dia. X Inner dia. : 275X180 (10.83X7.09)
CLUTCH (Power Shuttle)
Type : Wet Multi plate
Outer dia. X Inner dia. : 110X85 (4.33X3.35)
Each 6 pieces for F/R
TRANSMISSION
Type : synchro mesh
No. of gears : 24 forward,
24 reverse gears
with high and low
selection lever with
Differential Lock
STEERING : Hydraulic power
(Power steering)
POWER TAKE OFF
Rear mounted : 6 splines
Diameter : 1⅜ in.
Standard PTO : ①540 ②1000(750)
94
ELECTRICAL STARTING AND LIGHTING
Battery Capacity : 12 Volt
Starter : Solenoid Engaged.
Key Start with Safety ,
starter switch
Alternator : 12V 65A
Instrumentation : Water Temperature Gauge,
Taco meter, Hour meter,
Electrical fuel level gauge.
Lighting : Head lights, side indicators,
Rear parking,, brake &
indicator light, Front
parking & indicator light,
On dash board indicators
for battery charging, turn
signal, PTO signal, Engine
oil pressure, Preheat signal.
BRAKES
Foot operated, independent with provision of
inter lock for simultaneous operation. A foot
brake is fitted for parking.
Disc Diameter : Φ184mm(Φ7.24 in)
Number of lining : 5 each side
Total brake thickness : 59㎜(2.32in.)
HYDRAULIC SYSTEM
Independent fully”Live”hydraulic pump
and separate reservoir.Position controls with
isolating & response control
Hitch Lift capacity 1937Kgf(4270 lb)
at 24 inches behind link ends 1147Kgf(2528 lb)
Pump output : Main 18cc (46.8ℓ /min)
: Steering 8cc (20.8ℓ /min)
Delivery (91% efficiency): liter (cu.in) mm at
2600rpm
3 point linkage : category 2
adjustable outside stabilizer
