Tynetec Reach IP - GSM Signal Strength Indication; Delete Radio Devices; Deleting ALL Radio Devices; Home;Away Activity Function

4.4.1GSMSignalStrengthIndication
DuringRangeTestModetheStatusLEDwillindicatetheGSMsignalstrength,seetable
below;
GSMSignalStrength RSSI StatusLED
High
21‐31 SolidGreen
Good 11‐20 0.1SecFlashingGreen
Low 1‐10 0.5SecFlashingGreen
NoSignal 0 NotLit

4.5DeleteRadioDevices
PressthePowerbuttontoenterControlModethenpressandholduntiltheunit
announces“addradiodevice”thenrelease.Repeatedlypressuntiltheunit
announces“deleteradiodevices”thenpresstoconfirm.Activatetheradiodeviceto
be
removedandabeepwillbeheard.Pressandholduntilabeepisheard,andthe
unitwillannouncethenextfunction.

4.5.1DeletingALLRadioDevices
PressthePowerbuttontoenterControlModethenpressandholduntiltheunit
announces“addradiodevice”
thenrelease.Repeatedlypressuntiltheunit
announces“deleteradiodevices”thenpresstoconfirm.Pressandholduntila
beepisheardthenrelease.Pressandholdagainuntilabeepisheard,andtheunit
willannouncethenextfunction.

4.6Home/AwayActivity
Function
PressthePowerbuttontoenterControlModethenpressandholduntiltheunit
announces“addradiodevice”thenrelease.Repeatedlypressuntiltheunit
announces“homeawayactivityfunction”thenpresstoconfirm.Theunitwill
announceitscurrentstate;“function
isdisabled”or“functionisenabled”.Tochange
thesettingpressandholduntiltheunitannouncesthenewstate,theunitwillthen
announcethenextfunction.Note:ifenabledtheFunctionButtonisusedinidle
modetotoggleHome/Awaymode.
5.0ErrorIndications
Anerrorisindicatedbya“blurp”oravoicemessage;e.g.“powerdisconnected”or
“GSMnetworkfailure”.Thiswillrepeatevery2minutesuntiltheproblemisresolved
orthebuttonispressedtosilencethewarning.Errorsarealsoindicatedonthe
StatusLED,seethe
tablebelow;
StatusLED PossibleReason SuggestedAction
SolidGreen
NoGSM
networksignal
CheckGSMnetworksignalstrength
FlashingRed Mainsfailure
Checkmainssupplyand/orACadapter
connection
SolidAmber
Batteryfailure
ornotcharging
Check/replacebattery
Flashing
Green/Red/Amber
Radio
Interference
Checkinterferingradiosources.Move
DECTphones,WiFiRoutersetc.at
least1metreawayfromtheReachIP

6.0SwitchingtheReachIPOff
TheReachIPusesverylittlepowerandshouldalwaysbeleftswitchedon.Iftheunitis
beingremovedandstoredforaprolongedperiod,thenitshouldbeswitchedoff.
PressandholdthePowerbuttonuntilall3frontbuttons
andtheStatusLEDflash
oncethenrelease;theunitisnowswitchedoff.

7.0ImportantInformation
 Itisveryimportanttoreadandunderstandthissectionbeforeuse.
 Keeptheseinstructionsinasafeplaceforfuturereference.
7.1Use&Maintenance
• OperatingTemperatureRange:+5to
+45°C
• Donotdamagetheunitoritsparts,ifdamagedcontactyoursupplierimmediately
• Donotexposetodirectsunlight
• Keepawayfromdust,moistureanddirt
• Donotdrop,knock,twistorshakethedevice
• Donotwarmupthedeviceoruseitnearafire

7.2Cleaning
• AllpartsintheReachIPkitcanbecleanedwithamildsoapsolutionandadamp
cloth.Drywithasoftdrycloth.
• Strongchemicalsandotherharshsubstancesmustnotbeusedwhencleaningor
handlingthepartsinthe
ReachIPkit.
• TheReachIPmustbedisconnectedfromthemainssupplybeforecleaning.
• Aftercleaning,confirmthattheunitworksproperlybymakingatestalarmcalltothe
AlarmReceivingCentre.

7.3SafetyNotes
• Readinstructionsbeforeuse
• Alwaystesttheproductas
pertheinstructionsbeforeuse
• Alwayscheckthefunctionoftheproductaftermakingchangestosettings
• Thisproductmaynotbesuitableforallpersonsandshouldnotbeasubstitutefor
theroutinevisualmonitoringbyaCarer.
• Thisproductmustnotbeusedinsituations
whereadelayinthearrivalof
appropriatemedicalcarecouldleadtoapotentiallylife‐threateningsituation.
• Testtheproductregularlyandreplacewhennecessary.
• Donotintegratewithothersystemsotherthanthosespecifiedbythemanufacturer.
• Alwayskeeptheproductdry,exposuretoexcessive
moisturecancausemalfunction.
• Thisproductwillnotcauseelectromagneticdisturbancesundernormalworking
conditions.
• Thisproductcanbeplacednearotherproductsordevicesaslongasmechanical
vibrationisnotpresent.
• Removethebatteryiftheunitistobeoutofuseorstoredfor
anextendedperiod.
7.4Disposal
 Thecrossed‐outwheeliebinsymbolontheproductindicatesitisclassedas
 ElectricalorElectronicEquipmentandshouldnotbedisposedofincommercial
 wasteatitsendoflife.

TheWasteofElectrical&ElectronicEquipment(WEEE)Directive(2012/19/EU)has
beenputinplacetorecycleproductsusingthebestavailablerecoveryandrecycling
techniquestominimizeimpactontheenvironment,treathazardoussubstancesand
avoidincreasedlandfill.Forproductdisposalpleasecontactyoursuppliertocheckthe
termsand
conditionsofthepurchasecontract.Alwaysensurethisproductisnot
mixedwithcommercialwastefordisposal.








8.0Specification
• ReachIPcomplieswiththeSocialAlarmStandard:EN50134‐3:2012
• Dimensions:120mmx187mmx38mm(HxWxD)
• Weight:455grams(excPSU)
• PendantFrequency:869.2125MHz
• Maxtransmissionpower:50.000μV/m
• Protocols:TS50134‐9(SCAIP),BS8521&TT92
• PowerSupply:100‐240VAC50/60Hz<5Watts
• ACAdapterType:KSAS0050500100D5D(5VDC1.0ARated)
• BatteryType:3.6VNiMH1000mAh
9.0EUDeclarationofConformity
 Changesormodificationsnotexpresslyapprovedby
thepartyresponsiblefor
 compliancecouldvoidtheuser’sauthoritytooperatetheequipment.

ThisdevicecomplieswithEMCEmissions&ImmunityStandards;
EN61000‐6‐3:2007+A1:2011
EN50130‐4:2011+A11:2014
Operationissubjecttothefollowingtwoconditions:(1)Thisdevicemaynotcause
harmfulinterference,and(2)thisdevicemustacceptanyinterferencereceived,
includinginterferencethatmaycauseundesiredoperation.

ThisdevicecomplieswiththeRadioEquipmentDirective;
ETSIEN300220‐3‐1V2.1.1(2016‐12)
Theselimitsaredesignedtoprovidereasonableprotectionagainstharmful
interferenceinaresidentialinstallation.Thisequipmentcangenerate,useandradiate
radiofrequencyenergyand,ifnotinstalledandusedinaccordancewith
the
instructions,maycauseharmfulinterferencetoradiocommunications.However,
thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthis
equipmentdoescauseharmfulinterferencetoradioortelevisionreception,whichcan
bedeterminedbyturningtheequipmentoffandon,theuserisencouraged
totryto
correcttheinterferencebyoneormoreofthefollowingmeasures;
• Re‐orientateorrelocatethedevice
• Increasetheseparationbetweentheequipmentandreceiver
• ConnecttheequipmentintoaMainsoutletonacircuitdifferentfromthattowhich
thereceiverisconnected
•
Consultthesupplieroranexperiencedradio/TVtechnicianforhelp
ChrisDodd
ManagingDirector,LegrandAssistedLiving&HealthcareUK.


TynetecisabusinessunitofLegrandElectricLtd,
Unit10CowleyRoad,BlythRiversideBusinessPark,
Blyth,Northumberland,NE245TF,UK.
Tel:+44(0)1670352371Web:www.tynetec.co.uk
DocNo.FM0802V1.04
