FLIGHT CONTROLS
NOTICE: The safe distance between the TYPHOON Wizard™
and the aircraft is 39 ft (12m). The TYPHOON Wizard™ can
be controlled in different positions. Direction Control
Buttons function differently according to the positions of
the Wizard™.
1) When the TYPHOON Wizard™ is tilted upwards between
50° and 90°, the functions of the Direction Control Buttons are
as followed:
0°
50°
90°
2) When the TYPHOON Wizard™ is tilted upwards
between 0° and 40°, the functions of the Direction Control
Buttons are as followed:
0°
40°
90°
NOTICE: When the aircraft flies to the left or right side, the
nose of aircraft doesn't change its direction when the
TYPHOON Wizard™ is tilted upwards between 0° and 40°.
