Serial port output. Leave open if not used.
Serial port input with internal pull-up resistor to VCC. Leave open if
not used. Don‖t use external pull up resistor.
USB2.0 bidirectional communication pin. Leave open if unused.
Implementation see Section 1.5.2.
Hardware Reset
(Active Low)
Leave open if not used. Do not drive high.
Configurable Timepulse signal (one pulse per second by default).
Leave open if not used.
External Interrupt Pin.
Internal pull-up resistor to VCC. Leave open if not used.
LEA-5S, LEA-5A: Leave open for default configuration.
LEA-5H, LEA-5T: Reserved
DDC Data. Leave open if not used.
DDC Clock. Leave open if not used.
Leave open, do not drive low.
Can be left open, but connection to VCC is recommended for
compatibility reasons. I/O voltage is always VCC.
Table 4: Pin description LEA-5H/5S/5A/5T
2.2.3 Pin description for antenna designs (LEA-5Q/5M)
Provide clean and stable supply.
Assure a good GND connection to all GND pins of the module,
preferably with a large ground plane.
Connected to VCC. Leave open if not used.
It‖s recommended to connect a backup battery to V_BCKP in order
to enable Warm and Hot Start features on the receivers. Otherwise
connect to GND (or VCC).
To use the USB interface connect this pin to 3.0-3.6V derived from
VBUS.
If no USB serial port used connect to GND.
Defines the I/O voltage. Do not leave open.
GPS/GALILEO
signal input
from antenna
Use a controlled impedance transmission line of 50 Ohm to connect
to RF_IN.
Antenna bias voltage for active antennas is not provided on the
RF_IN pin. If an active Antenna is used an external voltage is
required (see Section 2.6.3).
Output Voltage
RF section
Serial port output. Leave open if not used.
Serial port input with internal pull-up resistor to VCC. Leave open if
not used. Don‖t use external pull up resistor.
USB2.0 bidirectional communication pin. Leave open if unused.
Implementation see Section 1.5.2.
