4-17
Section 4 - Parts
Item Part No. Part No. Part No. Description
Black White Stainless Steel
1 2303-S 2303-S 2303-S Condenser Assembly**
2 2800 2800 2800 Process tube
3 2694 2694 2694 Dryer
4 31434-1 31434-1 31434-1 Rivet, thermistor cover
5 26091 26091 26091 Cover, thermistor
6 41855 41855 41855 Screw, Evaporator
7 68092 68092 68092 Thermistor, quick connect white
8 68072-S 68072-S 68072-S Circuit Board Assembly
9 41992 41992 41992 Support, circuit board (included with 68072-S)
10 41993 41993 41993 Support, circuit board (included with 68072-S)
11 20026 20026 20026 Screw, reed switch
12 66010 66010 66010 Reed Switch
13 42162 42162 42162 Screw, 8-18 x .75, plastite
14 26089 26089 26089 Housing, display
15 68059-01 68059-01 68059-01 Display glass, Echelon control
16 68074 68074 68074 Display Assembly, Echelon
17 68080 68080 68080 Switch jumper (included with 68072-S)
18 21012-WHT 21012-WHT 21012-WHT Rivet, white
19 31726 31726 31726 Formed drain tube
20 31578 31578 31578 Washer, drain tube
21 11508 11508 11508 Drain cup
22 31391-3 31391-3 31391-3 Drain trough
23 41156 41156 41156 Screw, stainless steel
24 41158 41158 41158 Nut
25 11835 11835 11835 Clamp, thermistor
26 31213 31213 31213 Spacer, Evaporator
27 2333-S 2333-S 2333-S Evaporator Assembly**
Not N/A N/A 12091 Bushing, top pivot post
Shown
Not N/A N/A 14159-01 Commercial handle (SS accessory only)
Shown
Not 2950-01 2950-01 2950-01 Wire connector, 12-pin
Shown
**Part Includes Dryer & Process Tube
2175R (2 of 2)
