15 U-Line Service
Maintenance
• Make sure the shelves are inserted fully into the unit.
The edge strip toward the rear prevents cans and bottles
from freezing against the cold evaporator.
For models equipped with glass shelves having shelf supports, remove
the shelves as follows:
1. Open door completely.
2. Grasp the shelf edge in the center and slide the shelf from the unit.
Insert the shelves as follows:
Reposition the shelf as required, ensure the raised white edge
s
trip is toward the rear of the unit and graphics, if applied, are on
the underside of the shelves.
Wire Shelf Removal/Installation
For ADA models equipped with wire racks, reposition the shelves as
follows:
1. Remove shelf retention clip.
2. Pull shelf out about 6"
(1)
, until back of shelf clears the “hump” on
the right-hand side.
3. Tilt up right-hand edge of shelf
(2)
.
4. Remove shelf from unit by pulling out
(3)
.
Insert the shelves as follows:
1. To move to a different position in the unit, insert shelf at an angle,
a
pproximately 15-20°, over the rib in the side of the unit where
you want to place the shelf. The shelf must be started into the
unit at an angle to clear the door.
2. Continue to slide the shelf into the unit at an angle until it clears
the door.
3. Lower the shelf and push it in completely.
Install shelf retention clip.
