Height 1050mm*
8 9
02 Headlight
03 Handlebar Control
01 Frame
08 Battery
04 Console
11 Motors
Length 1820mm*
10 Tyres
05 Seat
06 Accessory Lugs
07 Suspension
09 Kickstand
01 Frame
The unique frame is designed for strength and
stiness whilst remaining light weight.
Constructed from 7020 Aluminium alloy, the frame
has excellent corrosion resistance.
It has a fixed rear carrier, removable front carrier
and lugs for carrying cargo. For full loading limits
and guidelines see Section 01: Safety.
02 Headlight
The Ubco 2×2 comes equipped with an 18W LED
headlight providing 1440 lumens of light output.
It is mounted to the handlebars via clamps,
allowing for easy angle adjustment.
03 Handlebar Control
The handlebars contain the operating controls of
the vehicle and headlight.
Controls include:
• Twist throttle.
• Horn.
• Front and rear brake levers.
04 Console
The front console houses the brains of the bike.
• Key ignition switch – turns the bike on and o.
• Battery level indicator – displays the remaining
charge of the battery.
• Headlight switch – turns the high intensity LED
light on and o.
• Drive mode – allows you to switch between full
power and eco motor output modes.
• Warning indicator – flashes when signalling a
warning (See page 42 for warning codes).
• 12v Power Port – allows you to charge power
tools and other devices (10A max).
• USB Charge Ports – allows you to charge
electronic devices.
05 Seat
The 2×2 has a large cushioned seat to provide
a comfortable platform for the rider to sit on. It
fastens to the frame via two plastic spring clips
and lifts up to allow you to remove the battery
from the frame.
Ensure the clips are securely engaged on the
frame before operating the vehicle.
*Height / Length measures are approximate.
