Rocket M Titanium
Hardware Overview
Connects to Sector
or Dish Antenna
Connects to Sector
or Dish Antenna
Connects to GPS
Patch Antenna
Removable Cover
Secondary (AUX)
Ethernet Port
Primary (MAIN)
Ethernet Port
LEDs
Main The first Ethernet LED will light steady green
when an active Ethernet connection is made to the
Primary Ethernet Port and flash when there is activity.
Aux The second Ethernet LED will light steady
green when an active Ethernet connection is made
to the Secondary Ethernet Port.
