MAX-M10S-Integration manual
Name Use Type / Value
C18 DC block 47 pF, 5%, 25 V, C0G
Table 36: Standard capacitors
C.2 Standard resistors
Table 37 presents the recommended resistor values for MAX-M10S.
Name Use Type / Value
R5 Antenna supervisor voltage divider 560 Ω, 5%, 0.1 W
R6 Antenna supervisor voltage divider 100 kΩ, 5%, 0.1 W
R7 Pull-up resistor at antenna supervisor transistor 100 kΩ, 5%, 0.1 W
R8 Antenna supervisor current limiter/shunt resistor 10 Ω, 5%, 0.25 W
Table 37: Standard resistors
C.3 Inductors
Table 38 presents the recommended inductor values for MAX-M10S.
Name Use Type / Value Recommended component
L3 RF Bias-T inductor 27 nH, 5%
Murata LQG15H, LQW15A series
Johanson Technology L-07W series
Any other inductor with impedance >500 Ω at GNSS
frequency and current rating above 300 mA.
Table 38: Recommended inductors
C.4 Operational amplifier
Name Manufacturer Order no.
U6 Linear Technology LT6000, LT6003
Table 39: Recommended parts list for the operational amplifier
C.5 Open drain buffers
Name Manufacturer Order no.
U7, U8 Fairchild NC7WZ07P6X
Table 40: Recommended parts list for the open drain buffers
C.6 Antenna supervisor switch transistors
Name Manufacturer Order no. Comments
T1, T2 Vishay Si1016X-T1-GE3 p-channel, n-channel MOSFET
Table 41: Recommended parts list for the antenna supervisor switch transistors
