8.1 INPUT KEY FUNCTION
MODE 2
S/N Mode/ Control Function
MODE 1
(1)
Throttle/Aileron Stick
Push the stick forward or backward and the quadcopter will
ascend or decend; Push the stick left or right and the quadcopter
will fly left or right.
Push the stick forward or backward and the quadcopter will
ascend or decend; Push the stick left or right and the quadcopter
will rotate counter clockwise or clockwise.
MODE 1
(2)
Elevator/Rudder Stick
Push the stick forward or backward and the quadcopter will fly
forward or backward;Push the stick left or right and the quadcopter
will rotate counter clockwise or clockwise.
Push the stick forward or backward and the quadcopter will fly
forward or backward;Push the stick left or right and the quadcopter
will fly left or right.
3
Aileron Trim Aileron trim adjusts for left and right drift.
4
Elevator Trim Elevator trim adjusts for forward and backward drift.
5
Rudder Trim Rudder trim adjusts for drift of left and right rotation or yaw.
6
Throttle Trim
Throttle trim is normally left at neutral. The lower trim turns LEDs
on and off.
7
Power Switch Push to turn on the transmitter. Push again to turn off.
MODE 2
2
Elevator /Aileron Stick
1
Throttle/ Rudder Stick
8
Video
Press video button to start recording and press again to stop.
14
©2015 Hubsan
