TABLE OF
CONTENTS
SAFETY INSTRUCTIONS 3
PRODUCT SPECIFICATIONS AND COMPONENTS 6
2.1| PRODUCT SPECIFICATIONS 6
2.2| PRODUCT PACKAGE 6
PRODUCT OUTLINE 7
3.1| FUNCTION BUTTONS 7
3.2| COMPONENT NAME 8
INSTRUCTIONS FOR USE 9
4.1| POWER SUPPLY 9
4.2| HOW TO TURN THE POWER ON/OFF 10
4.3| KF4 SLEEVE HEATER 10
4.4| SPLICE PROCEDURE 11
4.5| REMOVING THE SPLICED FIBER 12
4.6| HEATING PROTECTION SLEEVE 12
4.7| USE OF WORK BELT 13
MAINTENANCE OF SPLICE QUALITY 14
5.1| CLEANING AND INSPECTION BEFORE SPLICE 14
5.2| REGULAR INSPECTION AND CLEANING 15
MENU 17
POPUP MENU 19
6.1| SPLICE 22
6.2| HEATER 26
6.3| HISTORY (SPLICE RESULT) 31
6.4| OPTION 32
6.5| CALIBRATION 35
6.6| ELECTRODES 39
6.7| SETTING 42
6.8| INFORMATION 45
1 2
1
2
3
4
5
6
7
8
9
10
ERROR MESSAGES 48
7.1| TOO DIRTY FIBER 48
7.2| REPLACE FIBER 48
7.3| TOO LONG FIBER 49
7.4| FIBER OVER ANGLE 49
7.5| LOSS LIMIT OVER 50
7.6| FIBER THIN ERROR 50
7.7| FIBER THICK ERROR 50
7.8| BUBBLE ERROR 50
7.9| CLEAVED SURFACE ERROR 50
SPLICING PROBLEM SOLVING 51
8.1| WHEN LOSS IS HIGH 51
8.2| ABNORMAL SPLICING OPERATION 51
PROBLEM OCCURRENCES AND QUESTIONS 52
9.1| POWER 52
9.2| SPLICE 52
9.3| SLEEVE HEATER 53
9.4| OTHERS 53
WARRANTY AND REPAIR RESPONSIBILITY LIMIT 54
10.1| INFORMATION NECESSARY FOR REPAIR 54
10.2| TRANSPORTATION 54
10.3| REPAIR 54
