Uclan Ustym 4K PRO - Detailed Technical Specifications; Chipset and Tuner Technicals; Decoder and Demultiplexer Standards; Video & Audio Decoding

TECHNICAL SPECIFICATIONS
Main chipset
CPU: Multi-core 64-bit high-performance ARM Cortex A53 Hisilicon Hi3798MV200 (Huawei)
GPU: Multi-core high - performance GPU
Flash Memory: 8192MByte EMMC
SDRAM Memory: 1024MByte DDR3
DVBS Tuner
Tuner Type: Tuner RDA5815m
Frequency Range: 950~2150MHz:
Input Impedance: 75Ω
LNB Power and Polarisation: "Vertical 13VDC; Horizontal 18VDC @ 400mA (max)
22KHz ± 0.4KHz (0.6V ± 0.2V) tone, Overload Protection"
Input Level Range: -75dBm ~ -25dBm
DVBS Channel Decoder
DVBS Demodulator standard: DVB-S, DVB-S2, DVB-S2X
DVBS Demodulation: QPSK, 8PSK
DVBS Symbol Rate: 2~45MSPS
DVBS Code Rate:
DVBS: 1/2, 2/3, 3/4, 5/6, 7/8
DVBS2: 1/4, 1/3, 2/5, 1/2, 3/5, 2/3, 3/4, 5/6, 8/9, 9/10
TS Demux
Demultiplexer: MPEG2 ISO/IEC 13818-1
Input Bit Rate: Max 140Mbit/s
Video Decode
Video Decode: H.265/HEVC, AVS, H.264/AVC MVC, Real, MPEG-1//4, VC-1
Aspect Ratio: 4:3, 16:9
Video Resolution: Maximum 4K x 2K@60 fps 10-bit decoding
Audio Decode
Audio Decode: MPEG-1 layer I/II, MP3,
MPEG-4 AAC and AAC plus (HE-AACv1 and v2), DRA,
Dolby Digital (AC-3), Dolby Digital Plus (DD+)
Sound Mode: LEFT/ RIGHT/ STEREO/ MONO
Sampling Frequency: 32KHz, 44.1KHz, 48KHz
AV Output
Video Bandwidth: SD: 5.0MHz (-3dB), HD: 30MHz (-3dB)
Video Impedance: 75Ω
Video Voltage Level: 1.0 Vp-p
Audio Freq. Range: 20~20KHz
Audio Impedance: 600Ω
Audio Voltage Level: 2V rms (5.6Vp-p)
Environment
Input Voltage: AC 100~240V
，50Hz/60Hz
Consumption: Max 20W
Standby: <0.5W
Temperature: 0~40℃
Humidity: <95%
